Functions and features:
Structural composition:
The door body is made of double PVC coated polyester fabric? Composition, in the middle of the question? Aluminum or steel beams as wind-resistant skeletons.
It is equipped with movable rails, bottom beams, top frames, lifting mechanisms (motor + drum), sealing system and safety devices.
How to turn it on:
Vertical lifting, stacked folding, and the door cloth is folded above the opening after opening, without occupying indoor and outdoor space.
Performance Benefits:
Strong wind resistance: It can withstand level 12 typhoons, with a wind resistance load of 180N/m2, and can adapt to different wind pressures by adjusting the beam spacing. Light weight: Significantly reduces the requirements for the top structure of the door opening compared to traditional steel doors. Sealed insulation: with waterproof, sunproof, flame retardant, mildew-proof, moisture-proof, sound insulation, and thermal insulation? and other functions. Safety protection: equipped with anti-breaking lock, infrared sensing, airbag, low pressure control, warning device, etc
Adopting folding lifting mode and multiple built-in horizontal wind resistance rods, its wind pressure can be evenly distributed in the door curtain as a whole, and the wind resistance is much higher than that of ordinary roller type fast doors, especially suitable for logistics channels and large area openings, and wind pressure resistance
Stronger ability.
Fast stacking door products have the characteristics of fast opening speed, intelligent control, flexible opening and closing methods, including (geomagnetic control, radar control, infrared photoelectric, button, remote control, etc.)
Technical data:
Maximum height: 200000 mm
Maximum width: 350000 mm
Opening speed: 0.3-0.8 m/s Closing speed: 0.3-0.5 m/s Technique: Folding lifting method
Use: Internal and external departments, widely used in environments that require temperature control, noise control, hygiene control
