Wind-Resistant Roller Shutter Doors

Wind-Resistant Roller Shutter Doors

Product Introduction

Wind-resistant doors, also known as wind-resistant hook rolling doors or wind-resistant rolling shutter doors, are high-strength industrial protective doors designed for coastal typhoons and inland wind-sand areas. This product was jointly developed by multiple companies and is mainly used in building scenarios such as warehousing and factories that need to withstand extreme weather. The door body is formed by cold rolling galvanized plate, stainless steel plate, or colored plate, with built-in wind-resistant rails to prevent derailment. Its core wind resistance reaches 7845Pa, can withstand level 12 typhoons, and covers up to 15 meters in height and up to 20 meters. Integrates anti-pry, dustproof, soundproof, and thermal insulation functions, with bottom sealing strips and aluminum alloy rails for enhanced durability. Supports electric, manual, and remote control operation, suitable for slope or corner installation sites, opening and closing speed of 2-9 meters per minute, power supply compatible with 220-380V/50Hz. Compared to traditional rolling shutter doors, its wind-resistant hook design solves problems such as curtain panels easily blown off and ground troughs easily clogging. For coastal typhoon and inland sandstorm regions, the high-strength anti-air doors and wind-resistant panels are made from high-strength galvanized sheets with one-time cold rolling, offering high strength, good rigidity, and a robust structure. The guide rails have wind-resistant hooks to ensure the panels do not detach from the rails in strong winds, providing typhoon resistance, pry resistance, rainproofing, moisture resistance, noise insulation, cold resistance, insulation, sun protection, and wind and sand protection. Suitable for any construction field.

Application of the product

Wind-resistant rolling door curtain panels feature windproof, sign-proof, rainproof, noise-blocking, cold-proof, sunproof, wind-and-sand protection, among other functions; Suitable for any construction field. Our products are widely used in shopping malls, hotels, shopping plazas, stations, factories, and underground buildings
Garages and other areas.

Product features

Wind-resistant rolling door curtain panels feature windproof, sign-proof, rainproof, noise-blocking, cold-proof, sunproof, wind-and-sand protection, among other functions; Suitable for any construction field. Our products are widely used in shopping malls, hotels, shopping plazas, stations, factories, and underground buildings
Garages and other areas.
The door operator drives the roller through sprockets, causing the door curtain fixed on the roller to move up and down along the guide rails on both sides, enabling the opening and closing of the rolling door; When the roller shutter moves to the set upper and lower limit positions, the mechanical and electrical components of the rolling door are cut off through a limiter
Source causes the door to stop moving.
Wind-resistant curtain design uses Shanghai Baosteel’s 1.2mm color-coated panels, featuring wind-resistant hooks and activating the wind-resistant components when encountering extremely high wind pressure, capable of withstanding such strong wind pressure.
The track uses Shanghai Baosteel’s hot-dip galvanized steel plate, with a wind-resistant 120mm track design and a thickness of 2.0mm, coated with electrostatic powder coating. The track is equipped with soundproof sealing strips for low noise.
The drive system adopts a large drive shaft design with specially equipped auxiliary drive wheels to reduce operating noise, ensure the door curtain stays straight when the door is closed, and minimize door vibration.
Equipped with anti-chain breakage and anti-top-flush devices to ensure the safety of the door during operation. The bottom beam uses specially designed sealing rubber strips.
Equipped with a manual chain opening mechanism to ensure emergency activation after power outages.
Technical Data:
Maximum height: 12,000 mm; Maximum width: 16,000 mm; Opening speed: reach 0.6–1.0 meters/second; Closing speed: 0.6–1.0 meters/second; Method: Roller curtain method
Usage: Widely used in internal and external departments, widely used in environments requiring temperature control, noise control, and hygiene control
